JB/T 10236-2014: Rolling bearings. Vibration (velocity) for tapered roller bearings. Specifications
JB/T 10236-2014
JB
MECHANICAL INDUSTRY STANDARD
OF THE PEOPLE’S REPUBLIC OF CHINA
ICS 21.100.20
J 11
Filing No.: 45647-2014
Replacing JB/T 10236-2001
Rolling bearings - Vibration (velocity) for tapered roller
bearings - Specifications
ISSUED ON: MAY 06, 2014
IMPLEMENTED ON: OCTOBER 01, 2014
Issued by: Ministry of Industry and Information Technology of PRC
Table of Contents
Foreword ... 3
1 Scope ... 4
2 Normative references ... 4
3 Terms and definitions ... 4
4 Group code ... 4
5 Technical requirements ... 5
6 Measurement and evaluation methods ... 5
7 Inspection rules ... 5
Appendix A (Informative) Vibration (speed) limit of single tapered roller bearing
(nominal contact angle 23° < α ≤ 45°) ... 7
Foreword
This standard was drafted in accordance with the rules given in GB/T 1.1-2009.
This standard replaces JB/T 10236-2001 "Rolling bearings - Specifications of vibration
(velocity) for tapered roller bearings". Compared with JB/T 10236-2001, the main
technical changes are as follows:
- MODIFY the scope of application of the standard (see Chapter 1; Chapter 1 of the
2001 edition);
- MODIFY the division method of vibration (speed) limits (see Table 1; Table 1 of
the 2001 edition);
- MODIFY the vibration (speed) limits of small-size tapered roller bearings (see
Table 1; Table 1 of the 2001 edition);
- ADD the vibration (speed) limits for large-size tapered roller bearings (see Table
1);
- MODIFY the vibration (speed) measurement method of tapered roller bearings (see
Chapter 6; Chapter 5 of the 2001 edition);
- ADD the vibration (speed) limits for large taper angle tapered roller bearings (see
Appendix A).
This standard was proposed by China Machinery Industry Federation.
This standard shall be under the jurisdiction of the National Rolling Bearing
Standardization Technical Committee (SAC/TC 98).
Drafting organizations of this standard: Hangzhou Bearing Test and Research Center
Co., Ltd., Qianchao Bearing Co., Ltd., Fujian Yongan Bearing Co., Ltd., Zhejiang
Sitong Bearing Group Co., Ltd., Moshang Group Co., Ltd., Zhejiang Sibi Bearing Co.,
Ltd., Changshan Lutong Bearing Co., Ltd., Jinma Bearing (Zhejiang) Co., Ltd.
The main drafters of this standard: Zhang Youliang, Chen Fanghua, Shen Guoxiang,
Cai Binghua, Ma Lisha, Zhou Youhua, Zhang Jianjun, Zheng Xiaopeng, Peng
Zhenghua, Cao Maolai, Zhou Qibin, Lu Shuigan, Zhang Bin, Ma Shuiliang.
This standard replaces the standard previously issued as follows:
- JB/T 10236-2001.
Rolling bearings - Vibration (velocity) for tapered roller
bearings - Specifications
1 Scope
This standard specifies the technical conditions for vibration (speed) of single-row
tapered roller bearings, which have a nominal outer diameter of 30 mm ~ 200 mm.
Group V specified in this standard is the basic requirement for vibration (speed) of
general bearings. Group V1, Group V2, Group V3 are suitable for bearings which have
higher requirements for vibration (speed). This standard applies to production
inspection and user acceptance of tapered roller bearings.
2 Normative references
The following documents are essential to the application of this document. For the dated
documents, only the versions with the dates indicated are applicable to this document;
for the undated documents, only the latest version (including all the amendments) is
applicable to this standard.
GB/T 24608-2009 Inspection rules for rolling bearings and commercial parts
GB/T 24610.1-2009 Rolling bearings - Measuring methods for vibration - Part 1:
Fundamentals
GB/T 24610.3-2009 Rolling bearings - Measuring methods for vibration - Part 3:
Radial spherical and tapered roller bearings with cylindrical bore and outside surface
JB/T 2974-2004 Rolling bearings - Identification code - Supplemental regulations
3 Terms and definitions
The terms and definitions as defined in GB/T 24610.1-2009 apply to this document.
4 Group code
The vibration group codes given in JB/T 2974-2004 are applicable to this document.
