QC/T 1199-2023: Integrated AC standard socket-outlet of conductive charging for electric vehicles
QC/T 1199-2023
QC
AUTOMOBILE INDUSTRY STANDARD
ICS 43.040
CCS T 35
Integrated AC standard socket-outlet of conductive charging
for electric vehicles
ISSUED ON. DECEMBER 20, 2023
IMPLEMENTED ON. JULY 01, 2024
Issued by. Ministry of Industry and Information Technology of the PRC
Table of Contents
Foreword... 7
Introduction... 8
1 Scope... 9
2 Normative references... 9
3 Terms and definitions... 10
4 Technical requirements... 11
5 Test method... 17
6 Safety requirements for marking, packaging, transportation, storage... 21
Integrated AC standard socket-outlet of conductive charging
for electric vehicles
1 Scope
This document specifies the technical requirements, test methods, marking, packaging,
transportation, storage safety requirements of integrated AC power supply standard
sockets of conductive charging for electric vehicles.
This document is applicable to fixed integrated AC power supply standard sockets,
which have a rated voltage of 220 V and a rated current of 10 A of conductive charging
for electric vehicle.
2 Normative references
The contents of the following documents constitute essential clauses of this document
through normative references in the text. Among them, for reference documents with
dates, only the versions corresponding to the dates apply to this document; for reference
documents without dates, the latest versions (including all amendments) apply to this
document.
GB/T 1002-2021 Single phase plugs and socket-outlets for household and similar
purposes - Types, basic parameters and dimensions
GB/T 2099.1-2021 Plugs and socket-outlets for household and similar purposes -
Part 1.General requirements
GB/T 2408-2021 Plastics - Determination of burning characteristics - Horizontal
and vertical test
GB/T 2423.1-2008 Environmental testing for electric and electronic products - Part
2.Test methods - Tests A. Cold
GB/T 2423.2-2008 Environmental testing for electric and electronic products - Part
2.Test methods - Tests B. Dry heat
GB/T 2423.17 Environmental testing for electric and electronic products - Part 2.
Test method - Test Ka. Salt mist
GB/T 4208-2017 Degrees of protection provided by enclosure (IP code)
GB/T 7251.1-2013 Low-voltage switchgear and controlgear assemblies - Part 1.
General rules
GB/T 9254.1-2021 Information technology equipment, multimedia equipment and
receivers - Electromagnetic compatibility - Part 1.Emission requirements
GB/T 16422.2-2022 Plastics - Methods of exposure to laboratory light sources - Part
2.Xenon-arc lamps
GB/T 16916.1-2014 Residual current operated circuit-breakers without integral
overcurrent protection for household and similar uses (RCCB) - Part 1.General rules
GB/T 16935.1 Insulation coordination for equipment within low-voltage supply
systems - Part 1.Principles, requirements and tests
GB 18384-2020 Electric vehicles safety requirements
GB/T 18487.1-2023 Electric vehicle conductive charging system - Part 1.General
requirements
GB/T 18487.2-2017 Electric vehicle conductive charging system - Part 2.EMC
requirements for off-board electric vehicle supply equipment
GB/T 19596 Terminology of electric vehicles
GB/T 28569 Electric energy metering for electric vehicle AC charging spot
NB/T 33002-2018 Specification for electric vehicle AC charging spot
3 Terms and definitions
The terms and definitions as defined in GB/T 19596 and GB 18384-2020, as well as the
following terms and definitions, apply to this document.
3.1
Integrated AC power supply standard socket
Electric vehicles are charged using the AC charging connection device specified in
GB/T 18487.1-2023.The fixed device for charging and supplying power to electric
vehicles includes a single-phase two-pole grounded socket and other components
for protection, fixing, and other functions, such as boxes, columns, residual current
operated circuit breakers, etc.
3.2
Plug
2021.
4.4.3 The retention force of the single-phase two-pole grounded socket in the integrated
AC power supply standard socket shall meet the requirements of Chapter 22 of GB/T
2099.1-2021.
4.4.4 The plug-in and plug-out life of the single-phase two-pole grounded socket in the
integrated AC power supply standard socket shall meet the requirements of Chapter 21
of GB/T 2099.1-2021.
4.4.5 The integrated AC power supply standard socket shall be equipped with an AC
type residual current circuit breaker or a related device that meets the AC type residual
current protection function specified in GB/T 16916.1-2014.
4.4.6 The integrated AC power supply standard socket should be equipped with
necessary anti-theft devices.
4.5 Installation and maintenance requirements
4.5.1 The integrated AC power supply standard socket can be used for floor-standing
and wall-mounted installation.
4.5.2 All mechanical and electrical connections of the integrated AC power supply
standard socket shall be firm.
4.5.3 Integrated AC power supply standard sockets shall be easy to install and maintain.
4.6 Safety requirements
4.6.1 Protection against electric shock
Integrated AC power supply standard sockets shall meet the following requirements.
a) All high-voltage circuit parts shall meet the requirements of 5.1 personnel electric
shock protection in GB 18384-2020.Class B live parts shall be arranged in the
casing or behind the shield to prevent approaching the live parts from any
direction;
b) The electric shock protection device shall meet the requirements of Chapter 10 of
GB/T 2099.1-2021 for protection against electric shock;
c) The degree of protection of all live parts shall at least meet the IPXXB level
specified in GB/T 4208-2017;
d) The electrical clearance and creepage distance shall meet the requirements of
Chapter 8 of GB/T 7251.1-2013.When the altitude is greater than 2000 m, the
electrical clearance and creepage distance shall meet the requirements of GB/T
16935.1.
4.6.2 Grounding safety
The integrated AC power supply standard socket shall meet the following requirements.
a) The grounding terminal in the integrated AC power supply standard socket shall
meet the requirements of Chapter 11 Grounding measures in GB/T 2099.1-2021.
b) The exposed conductive parts of the integrated AC power supply standard socket,
including the exposed conductive shielding and shell, shall be able to be grounded
normally. The metal shell of the integrated AC power supply standard socket shall
be provided with a grounding bolt. According to the test method a) in 5.2, its
diameter shall not be less than 3 mm; there shall be a grounding mark. The door,
cover or similar parts of the integrated AC power supply standard socket shall be
connected to the main frame of the power supply standard socket with a protective
conductor. According to the test method b) in 5.2, the result requires that the cross-
sectional area of the protective conductor shall not be less than 1.5 mm2.
c) The resistance between any exposed conductive part of the integrated AC power
supply standard socket that can be touched by a person and the ground shall not
exceed 0.1 Ω; the measurement method shall be in accordance with the method
c) in 5.2.
4.6.3 Linkage safety
Integrated AC power supply standard sockets shall meet the following requirements
according to the test method of 5.3.
a) Integrated AC power supply standard sockets shall have the function of non-
powered insertion and non-powered removal;
b) The s...
